Cone Flow Element

Flow Measurement Excellence
  • Hydropneumatics Orifice Plate range is the most cost-effective Differential Pressure Measurement in accordance with ISO 5167-2, ISO TR-15377, AGA3 and ASME MFC-3M.
  • These devices are low maintenance with no moving parts and easy to handle and simple to install and operate.
  • Available in MOC suitable to your process needs ranging from Austenitic steels, Nickel Alloys, PVC, PTFE and Stellate coated.
Available Designs / Customizations
  • Square Edge Orifice Plates
  • - Process Flow Measurement of hydrocarbons, most gases and liquids
    - Custody Transfer and fiscal flow metering
  • Simple measurement
  • Conical Entrance & Quarter Circle
  • - Flow measurement of viscous fluids
    - Applications with low Reynolds numbers
  • Eccentric Plates & Segmental Plates
  • - Flow Measurement of dirty and contaminated fluids
    - Flow metering of fluids with suspended solids or entrained gas
Models Suitable for your need
  • CFE400# - Cone Flow Element
  • CFE400#M - Cone Flow Element with fully machined construction
  • CFE400#R - Cone Flow Element – Retrofittable design
  • CFE400#S - Cone Flow Element with Smart meter

Cone Flow Element

  • Client: Nuclear Power Corporation of India
  • Project: 2 x 700MW KAPP 3&4 & RAPP 7&8, Atomic Power Station.
  • Special Requirements:
  • - Accuracy must be +/- 0.5% Designed for Zero Straight length
    - Service: CEP discharge Condensate
    - Line Size: 18” NB, 300#
    - Design Temp: 110°C
    - Design Pressure: 27.5 Kg/cm2
